Category: I/O-Cards / Cardreader, PCI, Serial / Parallel

InLine® PCI Multi I/O Controller Card (2-Parallel Ports)

Art.-Nr.:66632I - EAN:4043718203055

This PCI multi-I/O card uses the latest PCI based Peripheral controller chipset from MosChip, enabling this card

to be installed on any PCI capable PC system. Most of the latest motherboards no longer come with serial or

parallel port. By using this card, end user can add serial and parallel ports to their PC system, allowing them to

connect their serial and parallel devices. This card offers superior performance and unmatched data transfer

rates. It is also ideal for industrial automation applications.

Easy installation, automatically selects IRQ and I/O address

Fully compliant with PCI Local Bus Specification Revision 2.3

Supports PCI power management

Supports PCI IRQ sharing feature, saves valuable resources for other add-on cards

Supports multiple cards on one PC

Supports DOS 6.22, Windows 2000, XP 32/64-bit, Server 2003 32/64-bit, Vista 32/64-bit, Server 2008

32/64-bit and Linux kernel 2.6.14 or above

Parallel Port (IEEE1284) interface: Supports SPP, PS2, EPP and ECP 1.9 mode, Fast data rate up to

1.5MBps, On-chip 256-byte FIFO

Package Contents: PCI multi-I/O card x 1, Standard mounting bracket x 1 (For 2nd Parallel Port), User

manual x 1, Software Driver CD x 1
